• DESIGN
  1-cylinder 4-stroke engine, water-cooled
• DISPLACEMENT
  200 cm³ (12.2 cu in)
• STROKE
  49 mm (1.93 in)
• BORE
  72 mm (2.83 in)
• COMPRESSION RATIO
  11.5:1
• CONTROL
  DOHC, 4 valves controlled via cam lever, chain drive
• INTAKE VALVE DIAMETER
  28.5 mm (1.122 in)
• EXHAUST VALVE DIAMETER
  24 mm (0.94 in)
• VALVE CLEARANCE, INTAKE, COLD
  0.08 … 0.12 mm (0.0031 … 0.0047 in)
• VALVE CLEARANCE, EXHAUST, COLD
  0.13 … 0.17 mm (0.0051 … 0.0067 in)
• CRANKSHAFT BEARING
  Two ball bearings
• CONROD BEARING
  Sleeve bearing
• PISTONS
  Cast light alloy
• PISTON RINGS
  1 compression ring, 1 tapered compression piston ring, 1 oil scraper ring
• ENGINE LUBRICATION
  Pressure circulation lubrication with 1 trochoidal pump
• PRIMARY TRANSMISSION
  22:72
• CLUTCH
  Clutch in oil bath / mechanically activated
• TRANSMISSION
  6-gear transmission, claw shifted

WEST MALAYSIA PLAN PACKAGE

REBATE RM2500

GIFT PACKAGE (BPACK_02):

DEPOSIT PLAN OTR

FREE GIFT:

1. Fullface Helmet
2. Jacket
3. Glove
4. Raincoat
5. Disc Lock
6. Roadtax Cover
7. Biker Mask
8. Arm Glove
9. Superbike Keychain
10. Handle Grip Accelerator
11. GPS Phone Holder
12. Tank Pad
13. Gear Lever Rubber Sock
14. Warranty 2 Years or 20,000km whichever earlier

EAST MALAYSIA PLAN PACKAGE

REBATE RM1500

GIFT PACKAGE (BPACK_02):

DEPOSIT PLAN OTR

FREE GIFT:

1. Fullface Helmet
2. Jacket
3. Glove
4. Raincoat
5. Disc Lock
6. Roadtax Cover
7. Biker Mask
8. Arm Glove
9. Superbike Keychain
10. Handle Grip Accelerator
11. GPS Phone Holder
12. Tank Pad
13. Gear Lever Rubber Sock
14. Warranty 2 Years or 20,000km whichever earlier
